We'll update our import.sql file since we don't need the master_plan data any more. Here's the entire query:

 drop schema if exists csvs cascade;
 create schema csvs;
 create table csvs.inms(
  sclk text,
  uttime text,
  target text,
  time_ca text,
  targ_pos_x text,
  targ_pos_y text,
  targ_pos_z text,
  source text,
  data_reliability text,
  table_set_id text,
  coadd_cnt text,
  osp_fil_1_status text,
  oss_fil_2_status text,
  csp_fil_3_status text,
  css_fil_4_status text,
  seq_table text,
  cyc_num text,
  cyc_table text,
  scan_num text,
  trap_table text,
  sw_table text,
  mass_table text,
  focus_table text,
  da_table text,
  velocity_comp text,
  ipnum text,
  mass_per_charge text,
  os_lens2 text,
  os_lens1 text,
  os_lens4 text,
  os_lens3 text,
  qp_lens2 text,
  qp_lens1 text,
  qp_lens4 text,
  qp_lens3 text,
  qp_bias text,
  ion_defl2 text,
  ion_defl1 text,
  ion_defl4 text,
  ion_defl3 text,
  top_plate text,
  p_energy text,
  alt_t text,
  view_dir_t_x text,
  view_dir_t_y text,
  view_dir_t_z text,
  sc_pos_t_x text,
  sc_pos_t_y text,
  sc_pos_t_z text,
  sc_vel_t_x text,
  sc_vel_t_y text,
  sc_vel_t_z text,
  sc_vel_t_scx text,
  sc_vel_t_scy text,
  sc_vel_t_scz text,
  lst_t text,
  sza_t text,
  ss_long_t text,
  distance_s text,
  view_dir_s_x text,
  view_dir_s_y text,
  view_dir_s_z text,
  sc_pos_s_x text,
  sc_pos_s_y text,
  sc_pos_s_z text,
  sc_vel_s_x text,
  sc_vel_s_y text,
  sc_vel_s_z text,
  lst_s text,
  sza_s text,
  ss_long_s text,
  sc_att_angle_ra text,
  sc_att_angle_dec text,
  sc_att_angle_tw text,
  c1counts text,
  c2counts text
 );
 copy csvs.inms
 from '[Absolute Path To]/cassini/csvs/inms.csv'
 delimiter ',' header csv;
 -- the header rows are included in the concatenated set
 -- removing
 delete from csvs.inms where sclk='sclk' or sclk is null;
